Dolphin-Scan Plus is a professional densitometer for 2-D Gel, SDS-PAGE, Western Blot, X-ray film, and serving for high resolution image capturing. Both transparent and reflecting modes are applicable for both dry and wet samples. Accomplished with Dolphin 1D software, scanning images can be analyzed within clicking.
- Specification
- Features
- Ordering
- Download
| Optical Resolution |
Epson Dual Lens System, 4800dpi and 6400dpi with Epson MatrixCCD® |
| Max. Hardware Resolution |
4800 x 9600dpi. 6400 x 9600dpi with Micro Step Drive® technology |
| Max. Interpolated Resolution |
12,800 x 12,800dpi |
| High Pass optics |
Anti-reflective optical coating and high reflection mirror |
| Optical Density |
4.0 D max |
| Color scan mode (bit depth) |
48 bits internal/ External |
| Monochrome Scan mode |
16 bits internal/ External |
| Max. reflective area |
8.5” x 11.7” |
| Color scan mode |
6-line color CCD - single pass |
| Light source |
White cold cathode fluorescent lamp |
| Computer connection |
Hi-speed USB 2.0 |
| Scan interface |
TWAIN compliant |
| Scanning speed |
4800dpi with High-Speed mode ; 10.8ms / line (approx.) with full color / monochrome mode |
The spec is subject to change without prior notice.
* Minimum computer system requirement for software analysis: Intel® Core™ i3-3240 3.4GHz, 1 G RAM with English version #Windows 10, Windows® 8 – 8.1, Windows 7, Windows Vista®, Windows XP, Windows XP Professional x64 Edition, more than two high-speed USB 2.0 or 3.0 supported.
# Windows is trademarks of Microsoft, Inc.
|
|
Features
Transparency adapter for different film sizes
Deliver the accurate images of gel sample
Unique high speed blue light scanning
Make batch scanning easily
1-D software available
Ordering Information
| Catalog Number |
Description |
| 1143002 |
Dolphin-Scan Plus Image system with Dolphin 1D software, 100 - 240V / 50 - 60Hz |
| 1144001 |
Advanced Dolphin-1D software for MW / Mass Determinatio, Colony Counting, Spot Density, and Microtiter Plate |
Download
| Flyer |
| Dolphin-Scan Plus |
 |
| Demo Software |
| Dolphin-1D |
 |
|
|
 |
Accessories |
|
|
|
|
| |
 |
| Dolphin-1D software |
|
Dolphin-1D is a powerful molecular image software package for use with the Wealtec Dolphin-series of image systems and scanners. Besides general image enhancements such as background subtraction and image filtering, all being easily traceble, Dolphin-1D has four major analysis functions; 1-D gel molecular weight/mass determination, microtiter plate analysis, spot density calculation and colony counting.
|
|
|
|
|
|
|
|
|
